GaAs INTEGRATED CIRCUIT
uPG2189TB
L-BAND 4W HIGH POWER SPST SWITCH
DESCRIPTION
The uPG2189TB is a GaAs SPST switch MMIC which was developed for high power application of multi-band and
multi-mode cellular handset. This device can operate frequency from 0.5GHz to 2.5GHz, having the low insertion loss
and high linearity performance.
FEATURES
? Control Voltage
? Low Insertion Loss
? High Linearity
? Surface mounting
: V cont （ H ） = 1.8V TYP.
: L ins1 = 0.30dB TYP. @ f = 1.0GHz, Vdd = 2.6V, V cont （ H ） = 1.8V
: L ins2 = 0.35dB TYP. @ f = 2.0GHz, Vdd = 2.6V, V cont （ H ） = 1.8V
: P in （ 0.1dB ） = ＞ +37.0dBm TYP.@ f = 1.0GHz, Vdd = 2.6V,V cont （ H ） = 1.8V
: 2fo = 68dBc TYP.@ f = 1.0GHz, Pin = +33dBm, Vdd = 2.6V, V cont （ H ） = 1.8V
: 3fo = 75dBc TYP.@ f = 1.0GHz, Pin = +33dBm, Vdd = 2.6V, V cont （ H ） = 1.8V
: 6-pin super mini-mold package （ 2.0 × 2.1 × 0.9 mm ）
APPLICATION
? High Power Application for Multi-band / multi-mode Cellular Handset
ORDERING INFORMATION
Part Number
uPG2189TB – E4
Order Number
uPG2189TB – E4 － A
Package
6-pin super
mini-mold
（ Pb-Free ）
Marking
G4T
Supplying Form
? Embossed tape 8 mm wide
? Pin4,5,6 face the perforation side
of the tape
? Qty 3 kpcs/reel
Remark T o order evaluation samples, contact your nearby sales office.
Part number for sample order : uPG2189TB-A
Caution Electro-static sensitive devices
The information in this document is being issued in advance of the production cycle for device.
The parameters for the device may change before final production or NEC Electronics Corporation, at its own
discretion, may withdraw the device prior to its production.
Document No. PG*****EJW1V0DS ( L rank )
Date Published March 2008 CP(K)
C NEC Electronics Corporation 2008
